Air Hoist >>GLX Series
Total Top Performance
Our GLX Series “San-Ei” Vane motors are most robust and reliable globally. This air chain hoists have a 100% duty cycle, anti-friction bearings and are globally proven for reliability in various environment conditions. These motors are designed for spark resistance operation. The chain guide gives maximum support with minimum chain wear and air hoist has brake design that works precisely for long life. These air hoists have the optimum efficiency,safety and Value.
This series is designed to handle weight range from 10 to 20 metric ton. These air hoists come standard with a pendant control and have complete range of options.
Our customers are delighted to use Air Hoists with longer life with minimum maintenance.
GLX FEATURES
The weight is very light compare to electrical
Gear Turbine Air Motor – High Performance
Smooth Feathering Control
Progressive Control with Keys (5:1)
Very Low Vibration
Durable Internal Disk Brake
Standard Load Chain: Grade T
Upper & Lower Limit Switch
Load Limiter
chain blocks of the same capacity
SPECIFICATIONS
| Model | Capacity (kg) |
Chain Fall (size×fall) | Pendent Switch (m) | Air Pressure (MPa) | Lifting Speed (m/min) | Air Consumption (N-max3 /min) |
Standard Lift (m) |
Weightt (kg) |
| GLX10LP | 10,000 | 2 | 2.5 | 0.5 | 1.6 | 6.2 | 3 | 260 |
| GLX15LP | 15,000 | 3 | 2.5 | 0.5 | 1.2 | 6.2 | 3 | 310 |
| GLX20LP | 20,000 | 4 | 2.5 | 0.5 | 0.8 | 6.2 | 3 | 330 |
