High Rigidity, Long Life

The Unique VMX Series “San-Ei” Vane motor air chain hoists have a 100% duty cycle, anti-friction bearings and have compact, light weight design. The speed of operation is infinitely variable from precise inching to high speed hoisting. These motors are designed for spark resistance qualities and work in robust environment. The chain guide gives maximum support with minimum chain wear and air hoist has brake design that works precisely for long life. The Japanese “San-Ei” Vane motor air hoists represent the optimum efficiency, safety and Value.

This series is designed to handle weight range from 1 to 2 metric ton. These air hoists come standard with a pendant control and have complete range of options. Lifts can be changed from standard 3 meters to as large as 20 meters for models VMX100 and 10 meters for VMX200. Further longer lifts are available optionally.

Our customers are delighted to use Air Hoists with longer life with minimum maintenance.

VMX Features

Special high speed operation on demand

Lift 3 to 20 meters

Longer lifts we can provide

Pendant Operation

Plain Trolley

Air Motor Trolley

Geared Trolley

Steel Bucket

Specifications

Capacity (kg)	Air Pressure (MPa)	Lifting Speed (m/min)	Air Consumption (N-max³ /min)	Lift (m)	String	Pendant Switch	Plain Trolley	Geared Trolley	Air Motor Trolley	Model	Weight (kg)
1000	0.6	5.0	1.6	3						VMX100LC	38
										VMX100LP	40
										VMX100LC-PR	54
	0.5	4.0	1.3							VMX100LP-PR	56
	0.5	4.0	1.3							VMX100LC-GR	61
	0.4	3.0	1.0							VMX100LP-GR	63
										VMX100LC-MR	62
										VMX100LP-MR	64
2000	0.6	2.5	1.6	3						VMX200LC	43
										VMX200LP	45
										VMX200LC-PR	63
	0.5	2.0	1.3							VMX200LP-PR	65
	0.5	2.0	1.3							VMX200LC-GR	70
	0.4	1.5	1.0							VMX200LP-GR	72
										VMX200LC-MR	72
										VMX200LP-MR	74
